Specifications
| Parameter | Description |
|---|---|
| Product Name | Pneumatic Angular Gripper |
| Series | MHC2 Series |
| Gripper Type | Angular Type |
| Number of Fingers | 2 Fingers |
| Action Type | Double Acting |
| Working Medium | Clean Air |
| Operating Pressure | 0.1~0.7 MPa |
| Body Material | Aluminum Alloy |
| Structure Type | Rack and Pinion Gripper Structure |
| Mounting Type | Multi-Side Mounting |
| Compatible with | SMC MHC2 Series |
| Applications | Pick-and-Place / Assembly / Transfer Systems |
How to order
Product Features
Compact Angular Gripper Design
Designed with a compact angular gripping structure for space-saving automation applications.
Stable Two-Finger Gripping
Provides reliable gripping performance for repeated workpiece handling operations.
Rack and Pinion Drive Structure
Supports smooth finger opening and closing motion with stable gripping force output.
Durable Aluminum Alloy Housing
Manufactured with durable aluminum alloy construction for long service life and reliable industrial operation.
High Repeatability Performance
Suitable for continuous pick-and-place and assembly automation applications.
Flexible Installation Structure
Supports multi-side mounting for easier integration into compact pneumatic systems.
Easy Industrial Replacement
Ideal replacement for SMC MHC2 Series in pneumatic angular gripper applications.
Applications
Pick-and-Place Systems
Used for gripping, transferring, and releasing workpieces in automated production lines.
Assembly Automation
Suitable for part handling, positioning, and loading applications in assembly systems.
Packaging Machinery
Applied in packaging automation equipment requiring stable angular gripping performance.
Material Handling Equipment
Provides reliable gripping movement for transfer, sorting, and feeding systems.
Robotic End-of-Arm Tooling
Suitable for EOAT systems requiring compact pneumatic angular gripping solutions.
Why Choose HOMIPNEU
- Compact angular gripper structure
- Stable two-finger gripping performance
- Rack and pinion drive design
- Durable aluminum alloy body construction
- Suitable for continuous industrial automation
- Flexible mounting for equipment integration
- OEM & ODM customization services
- Professional pneumatic gripper manufacturing support
FAQ
Is the MHC2 Series interchangeable with SMC MHC2 Series?
Yes, the MHC2 Series pneumatic angular gripper is designed to be interchangeable with SMC MHC2 Series in many industrial automation applications.
What is the MHC2 pneumatic gripper used for?
It is commonly used for pick-and-place systems, assembly automation, packaging machinery, transfer systems, and robotic handling applications.
What type of gripping structure is used?
The MHC2 Series uses a rack and pinion angular gripping structure for stable workpiece handling and smooth finger movement.
What working pressure range is supported?
The typical operating pressure range is approximately 0.1~0.7 MPa depending on application requirements.
Can OEM and ODM customization be supported?
Yes, OEM and ODM services are available, including customized finger structures, mounting configurations, logo branding, and packaging solutions.
OEM & ODM Support
HOMIPNEU provides professional OEM and ODM manufacturing services for pneumatic angular grippers, including customized finger structures, mounting options, logo branding, packaging solutions, and industrial automation support for distributors, machinery manufacturers, and pneumatic system integrators.
