PU220 Series 2/2 Way Brass Solenoid Valve

Specifications Model PU220-01AR PU220-02AR PU220-03AR PU220-03A PU220-04A PU220-06A PU220-08A Working Medium Air, Water, Oil Motion Pattern Direct Drive Type Type Normal Close Type Aperture of Flow Rate(mm) 1.5 2.3 8.00 13 13 20 25 CV Value 0.10 0.18 1.00 4.00 4.00 8.60 11.00 Joint Pipe Bore 1/8″ 1/4″ 3/8″ 3/8″ 1/2″ 3/4″ 1″ Operation Fluid Viscosity 50 CST Working-pressure(kgf/cm2) 0.5~7 Max. Pressure Resistance(kgf/cm2) 10.5 Operating Temperature Range(°C) -5~80 Model Selection and Dimensions Model Bore A B C PU220-01AR 1/8″ 30 62 22 PU220-02AR 1/4″ 30 62 22 PU220-03AR 3/8″ 55 78.5 30 PU220-03A 3/8″ 67.5 101 48 PU220-04A 1/2″ 67.5 101 48 PU220-06A 3/4″ 75 107 58 PU220-08A 1″ 96 121 70 Product Features 2/2 Way Normally Closed Design The PU220 Series uses a 2-port, 2-position normally closed structure. When the coil is not energized, the valve remains closed; when power is applied, the valve opens to allow medium flow. Brass Body for General Fluid Control The brass valve body provides stable strength and practical corrosion resistance for common air, water, oil, and compatible neutral fluid applications. Multiple Port Sizes…

Views: 95 2026-07-16

2S160-15D 2/2 Way Stainless Steel Solenoid Valve

Specifications Item Specification Model 2S160-15D Common Reference Model 2S160-15 Valve Type Stainless Steel Fluid Control Solenoid Valve Function 2/2 Way Position and Port Number 2 Port 2 Position Normal State Normally Closed Series 2S Series Port Size 1/2″ Orifice Size 16mm Working Medium Air, Water, Oil, Gas, Liquid, Vacuum and Compatible Neutral Fluids Operation Type Solenoid Operated / Direct Lift Diaphragm Type Body Material Stainless Steel Seal Material NBR / VITON Optional CV Value 4.8 Working Pressure Depends on medium, voltage and seal configuration Proof Pressure 1.2MPa Working Temperature -10°C to 80°C with NBR seal / -15°C to 120°C with VITON seal Voltage Options DC12V, DC24V, AC24V, AC110V, AC220V Electrical Entry DIN Connector / Lead Wire Type Structure Direct Lift Diaphragm Structure Flow Direction Follow the arrow direction on valve body Mounting Type Threaded Pipeline Connection Main Application Air, water, oil, gas and general pipeline on/off control Product Features 2/2 Way Normally Closed Design The 2S160-15D solenoid valve uses a 2-port, 2-position normally closed structure. When the coil is not energized, the valve remains closed; when power is applied, the…

Views: 60 2026-07-08

2S200-20G 2/2 Way Stainless Steel Solenoid Valve

Specifications Item Specification Model 2S200-20G Common Reference Model 2S200-20 Valve Type Stainless Steel Fluid Control Solenoid Valve Function 2/2 Way Position and Port Number 2 Port 2 Position Normal State Normally Closed Series 2S Series Port Size 3/4″ Orifice Size 20mm Working Medium Air, Water, Oil, Gas and Compatible Neutral Fluids Operation Type Solenoid Operated / Direct Lift Diaphragm Type Body Material Stainless Steel Seal Material NBR / VITON Optional CV Value 7.6 Working Pressure Depends on medium, voltage and seal configuration Proof Pressure 1.2MPa Working Temperature -5°C to 80°C Voltage Options DC12V, DC24V, AC24V, AC110V, AC220V Electrical Entry Lead Wire / Connector Type Structure Direct Lift Diaphragm Structure Flow Direction Follow the arrow direction on valve body Mounting Type Threaded Pipeline Connection Main Application Air, water, oil, gas and general pipeline on/off control Product Features 2/2 Way Normally Closed Design The 2S200-20G solenoid valve uses a 2-port, 2-position normally closed structure. When the coil is not energized, the valve remains closed; when power is applied, the valve opens to allow medium flow. 3/4 Port for Medium-Flow Pipeline Systems With…

Views: 50 2026-07-08

4V230C-08 5/3 Way Closed Center Solenoid Valve 1/4

Specifications Item Specification Model 4V230C-08 Valve Type Pneumatic Solenoid Valve Function 5/3 Way Position and Port Number 5 Port 3 Position Center Type Closed Center Control Type Double Solenoid Series 4V200 Series Port Size 1/4″ Exhaust Port Size 1/8″ Working Medium Filtered Compressed Air Operation Type Internal Pilot Type Body Material Aluminum Alloy Effective Sectional Area 13.6mm² CV Value 0.8 Working Pressure 0.15–0.8MPa Proof Pressure 1.2MPa Working Temperature -20°C to 70°C Voltage Options DC12V, DC24V, AC24V, AC110V, AC220V Electrical Entry DIN Connector / Terminal Type Structure Sliding Spool Structure Lubrication Not required Mounting Type Threaded Connection / Manifold Mounting Compatible Series Compatible with Airtac 4V200 Series Main Application Double-acting cylinder, pneumatic actuator, positioning control and industrial automation Product Features 5/3 Way Closed Center Design The 4V230C-08 solenoid valve uses a 5-port, 3-position structure with a closed center function. When the valve returns to the center position, the working ports are blocked, helping the cylinder or actuator stop and hold its current position. Double Solenoid Control The double solenoid structure allows electrical control in two directions. It is suitable for pneumatic…

Views: 67 2026-07-05

2V025-08 2/2 Way Normally Closed Solenoid Valve 1/4

Specifications Item Specification Model 2V025-08 Valve Type Fluid Control Solenoid Valve Function 2/2 Way Position and Port Number 2 Port 2 Position Normal State Normally Closed Operation Type Direct Acting Series 2V025 Series Port Size 1/4″ Orifice Size 2.5mm Working Medium Air, Water, Oil, Inert Gas Body Material Aluminum Alloy Seal Material NBR Working Pressure 0–0.8MPa Proof Pressure 1.2MPa Working Temperature -5°C to 80°C Voltage Options DC12V, DC24V, AC24V, AC110V, AC220V Electrical Entry DIN Connector / Lead Wire Type Response Type Fast On/Off Switching Lubrication Not required Mounting Type Threaded Connection Compatible Series Compatible with Airtac 2V025 Series Main Application Air, water, oil, gas and general fluid on/off control Product Features 2/2 Way Normally Closed Design The 2V025-08 solenoid valve uses a 2-port, 2-position normally closed structure. When the coil is de-energized, the valve remains closed; when the coil is energized, the valve opens to allow fluid flow. Direct Acting Operation The direct acting structure allows the valve to operate without requiring high differential pressure. This makes it suitable for small flow control, low-pressure circuits, and compact fluid control systems….

Views: 57 2026-07-03

4V130C-06 5/3 Way Closed Center Solenoid Valve 1/8

Specifications Item Specification Model 4V130C-06 Valve Type Pneumatic Solenoid Valve Function 5/3 Way Position and Port Number 5 Port 3 Position Center Type Closed Center Control Type Double Solenoid Series 4V100 Series Port Size 1/8″ Working Medium Filtered Compressed Air Operation Type Internal Pilot Type Body Material Aluminum Alloy Effective Sectional Area 8.6mm² CV Value 0.51 Working Pressure 0.15–0.8MPa Proof Pressure 1.2MPa Working Temperature -20°C to 70°C Voltage Options DC12V, DC24V, AC24V, AC110V, AC220V Electrical Entry DIN Connector / Terminal Type Structure Sliding Spool Structure Lubrication Not required Mounting Type Threaded Connection / Manifold Mounting Compatible Series Compatible with Airtac 4V100 Series Main Application Small double-acting cylinder, pneumatic actuator, positioning control and compact automation Product Features 5/3 Way Closed Center Design The 4V130C-06 solenoid valve uses a 5-port, 3-position structure with a closed center function. When the valve returns to the center position, the working ports are blocked, helping a cylinder or actuator stop and hold its current position. Double Solenoid Control The double solenoid structure allows electrical control in two directions. It is suitable for pneumatic systems that require…

Views: 73 2026-07-03

4V330C-10 5/3 Way Closed Center Solenoid Valve 3/8

Specifications Item Specification Model 4V330C-10 Valve Type Pneumatic Solenoid Valve Function 5/3 Way Position and Port Number 5 Port 3 Position Center Type Closed Center Control Type Double Solenoid Series 4V300 Series Port Size 3/8″ Exhaust Port Size 1/4″ Working Medium Filtered Compressed Air Operation Type Internal Pilot Type Body Material Aluminum Alloy Effective Sectional Area 21.3mm² CV Value 1.25 Working Pressure 0.15–0.8MPa Proof Pressure 1.2MPa Working Temperature -20°C to 70°C Voltage Options DC12V, DC24V, AC24V, AC110V, AC220V Electrical Entry DIN Connector / Terminal Type Structure Sliding Spool Structure Lubrication Not required Mounting Type Threaded Connection / Manifold Mounting Compatible Series Compatible with Airtac 4V300 Series Main Application Double-acting cylinder, pneumatic actuator, positioning control and industrial automation Product Features 5/3 Way Closed Center Design The 4V330C-10 solenoid valve uses a 5-port, 3-position structure with a closed center function. When the valve returns to the center position, the working ports are blocked, helping the cylinder or actuator stop and hold its current position. Double Solenoid Control The double solenoid structure allows electrical control in two directions. It is suitable for pneumatic…

Views: 61 2026-07-03

4V430C-15 5/3 Way Closed Center Solenoid Valve 1/2

Specifications Item Specification Model 4V430C-15 Valve Type Pneumatic Solenoid Valve Function 5/3 Way Position and Port Number 5 Port 3 Position Center Type Closed Center Control Type Double Solenoid Series 4V400 Series Port Size 1/2″ Working Medium Filtered Compressed Air Operation Type Internal Pilot Type Body Material Aluminum Alloy Effective Sectional Area 40mm² CV Value 2.35 Working Pressure 0.15–0.8MPa Proof Pressure 1.2MPa Working Temperature -20°C to 70°C Voltage Options DC12V, DC24V, AC24V, AC110V, AC220V Electrical Entry DIN Connector / Terminal Type Structure Sliding Spool Structure Lubrication Not required Mounting Type Threaded Connection / Manifold Mounting Compatible Series Compatible with Airtac 4V400 Series Main Application Double-acting cylinder, pneumatic actuator, positioning control and industrial automation Product Features 5/3 Way Closed Center Design The 4V430C-15 solenoid valve uses a 5-port, 3-position structure with a closed center function. When the valve returns to the center position, the working ports are blocked, helping the cylinder or actuator stop and hold its current position. Double Solenoid Control The double solenoid structure allows electrical control in two directions. It is suitable for pneumatic systems that require controlled…

Views: 53 2026-07-03

4V110-06 5/2 Way Single Solenoid Valve G1/8

Specifications Item Specification Model 4V110-06 Valve Type 5/2 Way Single Solenoid Valve Series 4V100 Series Port Size G1/8 Working Medium Filtered Compressed Air Operation Type Internal Pilot Type Body Material Aluminum Alloy Working Pressure 0.15–0.8MPa Proof Pressure 1.2MPa Working Temperature -20°C to 70°C Effective Sectional Area 10.2mm² CV Value 0.6 Max. Operating Frequency 5 cycles per second Lubrication Not required Compatible Series Compatible with Airtac 4V100 Series Application Pneumatic cylinder and actuator direction control Product Features Compact 5/2 Way Directional Control The 4V110-06 solenoid valve is designed for controlling double-acting pneumatic cylinders and other small pneumatic actuators. Its 5-port, 2-position structure allows reliable air direction switching in compact automation systems. G1/8 Port for Small Pneumatic Circuits With a G1/8 port size, this valve is suitable for compact pneumatic control panels, small cylinders, grippers, fixtures, and automatic production equipment where space is limited. Stable Internal Pilot Operation The internal pilot structure provides sensitive response and stable switching performance under normal compressed air conditions. It helps maintain consistent cylinder movement in repeated automation cycles. Durable Aluminum Alloy Body The aluminum alloy valve…

Views: 58 2026-07-03

3V310-10 3/2 Way Air Solenoid Valve G3/8

Specifications Parameter Description Product Name 3V310-10 3/2 Way Air Solenoid Valve Model 3V310-10 Valve Type 3/2 way pneumatic solenoid valve Port Function 3 ports, 2 positions Port Size G3/8 or 3/8 inch option, confirm thread type before ordering Working Medium Clean compressed air Actuation Type Single solenoid, spring return Typical Coil Voltage DC12V, DC24V, AC110V, AC220V options available Electrical Connection DIN connector, terminal type, or lead wire option depending on coil configuration Typical Application Single-acting cylinders, pneumatic fixtures, air control panels, and automation equipment Compatible Series Compatible with Airtac 3V300 Series Selection Checks Confirm port size, thread type, coil voltage, wiring type, pressure range, flow demand, connector type, and installation space before ordering Product Features 3/2 Way Directional Air Control The 3V310-10 is designed for compressed air switching in pneumatic systems that require one air inlet, one outlet, and one exhaust path. Its 3 port 2 position structure is suitable for single-acting actuator control and simple air circuit switching. G3/8 Port for Medium Flow Pneumatic Systems With a G3/8 port size, this valve is suitable for pneumatic circuits that need…

Views: 90 2026-07-01

3V1 3/2 Way Normally Closed Solenoid Valve for Air

Specifications Parameter Description Product Name 3V1 3/2 Way Normally Closed Solenoid Valve for Air Series 3V1 series Product Type 3/2 way normally closed pneumatic solenoid valve Working Medium Compressed air Main Function directional air control for pneumatic cylinders and actuators Control Method Solenoid or manual control depending on valve type Selection Checks Confirm way and position type, port size, coil voltage, connector type, pressure range, flow requirement, mounting style, and manifold compatibility before ordering Applications Automation equipment, pneumatic systems, process equipment, machine panels, and OEM assemblies Product Features Directional Air Control The valve changes the air path to control pneumatic actuator movement according to the electrical signal. Suitable for Cylinder Circuits It is used for pneumatic cylinders, grippers, slides, and machine actuators that require controlled movement direction. Panel and Manifold Use The valve can be integrated into machine panels or manifold systems when the base, port size, and wiring match. Stable Switching Performance Clean compressed air, correct voltage, and proper installation help maintain reliable response in repeated cycles. Industrial Valve Supply The 3V1 can be supplied for automation equipment, machine…

Views: 179 2026-05-17

2V025 2/2 Way Normally Closed Solenoid Valve for Air

Specifications Parameter Description Product Name 2V025 2/2 Way Normally Closed Solenoid Valve for Air Series 2V series Product Type 2/2 way normally closed solenoid valve Working Medium Compressed air, water, or compatible media depending on specification Main Function on-off control for compressed air or compatible fluid lines Control Method Solenoid or manual control depending on valve type Selection Checks Confirm normally closed or normally open function, orifice size, port size, coil voltage, pressure range, body material, seal material, and medium compatibility before ordering Applications Automation equipment, pneumatic systems, process equipment, machine panels, and OEM assemblies Product Features Two Way On-Off Control The valve opens or closes the flow path for compressed air or compatible media according to the coil signal. Direct Acting Valve Structure Direct acting models support compact installation and simple control logic in small air or fluid circuits. Normally Closed or Normally Open Options The correct function should be selected according to whether the circuit must stay closed or open when de-energized. Compact Installation The small valve body is suitable for control boxes, machine panels, and equipment with…

Views: 164 2026-05-17
