Specifications
| Item | Specification |
|---|---|
| Model | 2V025-08 |
| Valve Type | Fluid Control Solenoid Valve |
| Function | 2/2 Way |
| Position and Port Number | 2 Port 2 Position |
| Normal State | Normally Closed |
| Operation Type | Direct Acting |
| Series | 2V025 Series |
| Port Size | 1/4″ |
| Orifice Size | 2.5mm |
| Working Medium | Air, Water, Oil, Inert Gas |
| Body Material | Aluminum Alloy |
| Seal Material | NBR |
| Working Pressure | 0–0.8MPa |
| Proof Pressure | 1.2MPa |
| Working Temperature | -5°C to 80°C |
| Voltage Options | DC12V, DC24V, AC24V, AC110V, AC220V |
| Electrical Entry | DIN Connector / Lead Wire Type |
| Response Type | Fast On/Off Switching |
| Lubrication | Not required |
| Mounting Type | Threaded Connection |
| Compatible Series | Compatible with Airtac 2V025 Series |
| Main Application | Air, water, oil, gas and general fluid on/off control |
Product Features
2/2 Way Normally Closed Design
The 2V025-08 solenoid valve uses a 2-port, 2-position normally closed structure. When the coil is de-energized, the valve remains closed; when the coil is energized, the valve opens to allow fluid flow.
Direct Acting Operation
The direct acting structure allows the valve to operate without requiring high differential pressure. This makes it suitable for small flow control, low-pressure circuits, and compact fluid control systems.
1/4 Port for General Fluid Control
With a 1/4″ port size, the 2V025-08 is suitable for air, water, oil, inert gas, and other compatible media used in automation equipment and fluid control systems.
Compact Aluminum Alloy Body
The aluminum alloy body provides light weight, practical strength, and good corrosion resistance for general industrial environments.
Fast On/Off Response
The compact internal structure supports quick opening and closing, helping improve response speed in automated fluid control applications.
Normally Closed Safety Function
The normally closed design helps shut off the flow automatically when power is removed, making it useful for applications where the default state should be closed.
Multiple Voltage Options Available
The 2V025-08 can be supplied with common voltage options such as DC12V, DC24V, AC24V, AC110V, and AC220V to match different control systems.
Ideal Replacement for Airtac 2V025 Series Applications
The 2V025-08 can be selected for systems that require a compact 2/2 way normally closed direct acting solenoid valve compatible with Airtac 2V025 Series installations.
Applications
The 2V025-08 solenoid valve is widely used in air control systems, water control equipment, oil circuits, gas control lines, pneumatic systems, automatic filling equipment, cooling systems, laboratory devices, small fluid control panels, cleaning equipment, and industrial automation machines.
It is especially suitable for applications where a compact valve is needed to control fluid on/off flow by electrical signal. The normally closed structure makes it useful for systems that need the flow path to remain shut when power is off.
Why Choose HOMIPNEU
HOMIPNEU supplies solenoid valves, pneumatic valves, manual valves, cylinders, fittings, and air source treatment components for industrial automation and fluid control systems. The 2V025-08 solenoid valve is designed for compact installation, reliable on/off switching, and practical use in air, water, oil, and gas control applications.
We support voltage selection, thread options, model matching, batch supply, labeling, packaging, and customized requirements for OEM machinery builders, pneumatic distributors, maintenance users, and industrial equipment suppliers.
FAQ
What is the 2V025-08 solenoid valve used for?
The 2V025-08 is mainly used for on/off control of air, water, oil, inert gas, and other compatible fluids.
Is 2V025-08 a 2/2 way valve?
Yes. The 2V025-08 is a 2-port, 2-position solenoid valve.
Is the 2V025-08 normally closed?
Yes. The valve is normally closed, which means it stays closed when the coil is not energized and opens when power is applied.
What is the port size of 2V025-08?
The standard port size is 1/4″, commonly used in compact fluid and pneumatic control systems.
Is 2V025-08 direct acting?
Yes. The 2V025-08 uses a direct acting structure, suitable for small-flow and low-pressure control applications.
Can 2V025-08 be used for water?
Yes. It can be used for water if the pressure, temperature, seal material, and fluid compatibility match the system requirements.
What is the difference between 2V025-08 and 4V210-08?
The 2V025-08 is a 2/2 way normally closed valve mainly used for fluid on/off control. The 4V210-08 is a 5/2 way directional solenoid valve mainly used for controlling double-acting pneumatic cylinders.
Is this valve interchangeable with Airtac 2V025 Series?
The 2V025-08 is designed for 2V025 series type fluid control valve applications and can be selected for systems using Airtac 2V025 Series style valves.
OEM & ODM Support
HOMIPNEU provides OEM & ODM support for fluid control solenoid valves, including voltage options, thread options, coil selection, labeling, packaging, and batch supply for automation equipment manufacturers, pneumatic distributors, maintenance users, and industrial equipment suppliers.
