Specifications
| Item | Specification |
|---|---|
| Model | 4M210-08 |
| Valve Type | NAMUR Solenoid Valve |
| Function | 5/2 Way |
| Control Type | Single Solenoid |
| Series | 4M200 Series |
| Port Size | 1/4″ |
| Working Medium | Filtered Compressed Air |
| Operation Type | Internal Pilot Type |
| Body Material | Aluminum Alloy |
| Working Pressure | 0.15–0.8MPa |
| Proof Pressure | 1.2MPa |
| Working Temperature | -20°C to 70°C |
| Voltage Options | DC12V, DC24V, AC24V, AC110V, AC220V |
| Power Connection | DIN Connector / Terminal Type |
| Lubrication | Not required |
| Mounting Type | NAMUR Interface Mounting |
| Compatible Series | Compatible with Airtac 4M200 Series |
| Main Application | Pneumatic actuator, rotary actuator, cylinder and automated valve control |
Product Features
NAMUR Interface for Direct Actuator Mounting
The 4M210-08 solenoid valve is designed with a NAMUR mounting interface, making it suitable for direct installation on compatible pneumatic actuators. This design helps reduce external tubing, simplify the air circuit, and save space inside valve automation systems.
5/2 Way Directional Air Control
The 5-port, 2-position structure allows the 4M210-08 to control the air direction of double-acting pneumatic actuators, rotary actuators, and cylinders. It is commonly used where stable open and close control is required.
Single Solenoid Operation
The single solenoid design provides simple and reliable switching. When the coil is energized, the valve shifts position; when power is removed, it returns to its normal state, supporting repeatable actuator movement in automation equipment.
1/4 Port for Practical Airflow Control
With a 1/4″ port size, the 4M210-08 provides suitable airflow capacity for small and medium pneumatic actuator systems, automated valves, and general industrial compressed air circuits.
Internal Pilot Structure
The internal pilot design supports sensitive response and stable valve operation under normal compressed air conditions. It helps maintain smooth switching during repeated actuator cycles.
Sliding Spool Design
The sliding spool structure provides good sealing performance, low friction, and stable movement, helping improve long-term reliability in pneumatic control applications.
No Extra Lubrication Required
The valve can operate in clean compressed air systems without additional oil lubrication. This helps reduce maintenance work and keeps the pneumatic circuit cleaner.
Ideal Replacement for Airtac 4M200 Series Applications
The 4M210-08 can be selected for pneumatic actuator systems that require a NAMUR type 5/2 way solenoid valve compatible with Airtac 4M200 Series installations.
Applications
The 4M210-08 NAMUR solenoid valve is widely used in pneumatic actuator control, automated ball valves, butterfly valves, rotary actuators, double-acting cylinders, packaging machinery, process automation equipment, industrial control panels, and factory automation systems.
It is especially suitable for applications where the solenoid valve needs to be mounted directly onto a pneumatic actuator through a NAMUR interface. This helps reduce tubing, simplify installation, and improve the overall stability of the pneumatic control system.
Why Choose HOMIPNEU
HOMIPNEU supplies pneumatic solenoid valves for automation equipment, actuator control systems, valve automation projects, and industrial compressed air circuits. The 4M210-08 NAMUR solenoid valve is designed for stable switching, easy installation, and practical compatibility with common pneumatic actuator mounting requirements.
We support voltage selection, model matching, batch supply, labeling, packaging, and customized requirements for OEM machinery builders, valve automation suppliers, pneumatic distributors, and industrial equipment manufacturers.
FAQ
What is the 4M210-08 solenoid valve used for?
The 4M210-08 is mainly used to control pneumatic actuators, rotary actuators, double-acting cylinders, and automated valve systems.
Is 4M210-08 a NAMUR solenoid valve?
Yes. The 4M210-08 is a NAMUR type pneumatic solenoid valve designed for direct actuator mounting.
Is the 4M210-08 a 5/2 way valve?
Yes. It is a 5-port, 2-position valve suitable for controlling double-acting pneumatic actuators and cylinders.
What is the port size of 4M210-08?
The standard port size is 1/4″, which is commonly used in pneumatic actuator and automated valve control systems.
What is the difference between 4M210-08 and 4M310-08?
Both are NAMUR type solenoid valves, but 4M210-08 belongs to the 4M200 Series, while 4M310-08 belongs to the 4M300 Series. The 4M310-08 is generally selected for applications that need a larger valve body or higher airflow capacity.
Can 4M210-08 be mounted directly on a pneumatic actuator?
Yes. The NAMUR interface allows direct mounting on compatible pneumatic actuators, reducing external tubing and simplifying installation.
Is this valve interchangeable with Airtac 4M200 Series?
The 4M210-08 is designed for NAMUR pneumatic valve applications and can be selected for systems using Airtac 4M200 Series style valves.
Does the 4M210-08 need oil lubrication?
No. In a clean compressed air system, additional oil lubrication is generally not required.
OEM & ODM Support
HOMIPNEU provides OEM & ODM support for NAMUR solenoid valves, including voltage options, coil selection, labeling, packaging, and batch supply for actuator manufacturers, valve automation suppliers, pneumatic distributors, and industrial equipment builders.
