Specifications
| Item | Specification |
|---|---|
| Model | 4M310-08 |
| Valve Type | 5/2 Way NAMUR Solenoid Valve |
| Control Type | Single Solenoid |
| Series | 4M300 Series |
| Port Size | 1/4″ |
| Working Medium | Filtered Compressed Air |
| Operation Type | Internal Pilot Type |
| Body Material | Aluminum Alloy |
| Working Pressure | 0.15–0.8MPa |
| Proof Pressure | 1.2MPa |
| Working Temperature | -20°C to 70°C |
| Voltage Options | DC12V, DC24V, AC24V, AC110V, AC220V |
| Power Connection | DIN Connector / Terminal Type |
| Lubrication | Not required |
| Mounting Type | NAMUR Interface Mounting |
| Compatible Series | Compatible with Airtac 4M300 Series |
| Application | Pneumatic actuator, rotary actuator, cylinder and valve automation control |
Product Features
NAMUR Interface for Direct Actuator Mounting
The 4M310-08 solenoid valve is designed with a NAMUR mounting interface, making it suitable for direct installation on pneumatic actuators and automated valve control systems. This structure helps reduce piping, save space, and simplify installation.
5/2 Way Directional Air Control
With a 5-port, 2-position structure, the 4M310-08 provides reliable air direction switching for double-acting pneumatic actuators, cylinders, and valve automation equipment.
Single Solenoid Operation
The single solenoid design allows the valve to shift when energized and return when de-energized. This makes it practical for applications that require simple, stable, and repeatable actuator control.
1/4 Port for Industrial Pneumatic Systems
The 1/4 port size provides suitable airflow capacity for many medium-sized pneumatic actuators and industrial air control circuits.
Durable Aluminum Alloy Valve Body
The aluminum alloy body offers good mechanical strength, stable thread quality, and reliable performance in general factory automation environments.
Stable Spool Switching Performance
The internal spool structure is designed for smooth movement, responsive switching, and consistent sealing performance during repeated operation.
Multiple Voltage Options Available
The 4M310-08 can be supplied with common voltage options such as DC12V, DC24V, AC24V, AC110V, and AC220V to match different control systems.
Ideal Replacement for Airtac 4M300 Series Applications
The 4M310-08 can be selected for pneumatic systems that require a NAMUR type 5/2 way solenoid valve compatible with Airtac 4M300 Series installations.
Applications
The 4M310-08 NAMUR solenoid valve is widely used in pneumatic actuator control, automated ball valves, butterfly valves, rotary actuators, double-acting cylinders, process automation systems, packaging machinery, industrial control panels, and factory automation equipment.
It is especially suitable for applications where the solenoid valve needs to be mounted directly onto a pneumatic actuator through a NAMUR interface, helping reduce external tubing and improve installation efficiency.
Why Choose HOMIPNEU
HOMIPNEU supplies reliable pneumatic solenoid valves for automation equipment, pneumatic actuator systems, and industrial air control solutions. The 4M310-08 NAMUR valve is designed for stable switching, easy installation, and practical compatibility with common pneumatic actuator mounting requirements.
We support model selection, voltage options, batch supply, labeling, packaging, and customized requirements for OEM machine builders, valve automation suppliers, and pneumatic distributors.
FAQ
What is the 4M310-08 solenoid valve used for?
The 4M310-08 is mainly used to control the air direction of pneumatic actuators, rotary actuators, double-acting cylinders, and automated valve systems.
Is 4M310-08 a NAMUR solenoid valve?
Yes. The 4M310-08 is a NAMUR type pneumatic solenoid valve designed for actuator mounting applications.
Is the 4M310-08 a 5/2 way valve?
Yes. It is a 5-port, 2-position solenoid valve suitable for double-acting pneumatic actuator control.
What is the port size of 4M310-08?
The standard port size is 1/4″, commonly used in industrial pneumatic actuator systems.
Can 4M310-08 be mounted directly on a pneumatic actuator?
Yes. Its NAMUR interface allows direct mounting on compatible pneumatic actuators, reducing the need for extra tubing.
Is this valve interchangeable with Airtac 4M300 Series?
The 4M310-08 is designed for NAMUR type pneumatic valve applications and can be selected for systems using Airtac 4M300 Series style valves.
What voltage options are available?
Common options include DC12V, DC24V, AC24V, AC110V, and AC220V. Final voltage should be selected according to the control system.
OEM & ODM Support
HOMIPNEU provides OEM & ODM support for NAMUR solenoid valves, including voltage selection, coil options, labeling, packaging, and batch supply for actuator manufacturers, valve automation suppliers, pneumatic distributors, and industrial equipment builders.
