Specifications
| Parameter | Details |
|---|---|
| Product Type | Pneumatic Fittings |
| Series | C Type Quick Fitting Series |
| Structure | Elbow (90°) |
| Connection | Tube to Tube |
| Installation | Push-to-Connect |
| Material | Nickel-Plated Brass / Stainless Steel (Optional) |
| Operating Fluid | Air |
| Working Pressure | 0 – 1.0 MPa |
| Temperature Range | 0 – 60°C |
| Applicable Tubing | PU / Nylon Tube |
Elbow fittings provide efficient airflow direction change while maintaining reliable sealing and compact installation.
Model: Model: (Example PVT4)
| 4 |
| 6 |
| 8 |
| 10 |
| 12 |
| 14 |
| 16 |
Key Features
- 90° elbow structure for airflow direction change
- Push-to-connect quick installation
- Compact design for tight installation spaces
- Smooth airflow transition
- Multiple material options for different environments
- Reliable sealing and long service life
Applications
Pneumatic control systems
Used for changing airflow direction in tube routing
Industrial automation equipment
Ensures flexible connection in complex systems
Air distribution systems
Supports organized piping layouts
Machinery equipment
Ideal for space-constrained pneumatic installations
PU and nylon tubing systems
Compatible with standard pneumatic tubing
Product Function
PVT fittings are used to connect pneumatic tubing at a 90-degree angle, allowing airflow direction change without compromising system performance.
They help optimize tubing layout, reduce bending stress, and improve overall system efficiency.
Compared to straight fittings, elbow fittings provide greater flexibility in compact pneumatic systems.
Product Structure & Size Range
- Models: PVT4 / PVT6 / PVT8 / PVT10 / PVT12
- Tube sizes: 4mm → 12mm
- 90° elbow structure
- Push-to-connect tube interface
- Compact connection design
Why Choose Our Pneumatic Fittings
- Professional PVT pneumatic fitting manufacturer
- OEM / ODM customization for elbow pneumatic fittings
- Reliable push to connect elbow connector solution
- Multiple material options including stainless steel
- Suitable for complex pneumatic routing systems
- Fast delivery and global B2B supply support
FAQ
Q1: What is a PVT pneumatic fitting?
It is a push-to-connect elbow fitting used for 90-degree tube connection.
Q2: What is an elbow pneumatic fitting used for?
It is used to change airflow direction in pneumatic systems.
Q3: What materials are available for PVT fittings?
PVT fittings are available in nickel-plated brass and stainless steel options.
Q4: What tubing is compatible with PVT fittings?
PVT fittings are suitable for PU tubing and nylon tubing.
Q5: Can PVT fittings be customized?
Yes, OEM/ODM customization is available for size, material, and branding.
