Specifications
| Parameter | Details |
|---|---|
| Product Type | Pneumatic Fittings |
| Series | C Type Quick Fitting Series |
| Structure | Straight Reducer |
| Connection | Tube to Tube |
| Installation | Push-to-Connect |
| Material | Nickel-Plated Brass / Stainless Steel (Optional) |
| Operating Fluid | Air |
| Working Pressure | 0 – 1.0 MPa |
| Temperature Range | 0 – 60°C |
| Applicable Tubing | PU / Nylon Tube |
Straight reducer fittings allow efficient tube size conversion while maintaining stable airflow and compact system design.
Model: Model: (Example PGT6-4)
| 6-4 | 12-6 |
| 8-4 | 12-8 |
| 8-6 | 12-10 |
| 10-4 | |
| 10-6 | |
| 10-8 |
Key Features
- Straight reducer structure for tube size conversion
- Smooth airflow without direction change
- Push-to-connect quick installation
- Compact inline design for space saving
- Multiple material options for different environments
- Reliable sealing and stable performance
Applications
Pneumatic control systems
Used for connecting different tube sizes in air circuits
Industrial automation equipment
Ensures smooth airflow during size transition
Air distribution systems
Supports efficient tube routing and layout optimization
Machinery equipment
Ideal for compact systems requiring diameter reduction
PU and nylon tubing systems
Compatible with standard pneumatic tubing
Product Function
PGT fittings are used to connect two pneumatic tubes of different diameters in a straight line.
They provide seamless airflow transition without changing direction, helping reduce turbulence, simplify system structure, and improve overall pneumatic efficiency.
Compared to standard straight unions, PGT fittings add reducer functionality, making them essential for mixed tube size systems.
Product Structure & Size Range
- Models: PGT4-6 / PGT6-8 / PGT8-10 / PGT10-12
- Tube sizes: 4mm → 12mm (various combinations)
- Straight inline reducer design
- Push-to-connect tube interface
- Compact connection structure
Why Choose Our Pneumatic Fittings
- Professional PGT pneumatic fitting manufacturer
- OEM / ODM customization for straight reducer fittings
- Reliable push to connect reducer connector solution
- Multiple material options including stainless steel
- Suitable for mixed tube size pneumatic systems
- Fast delivery and global B2B supply support
FAQ
Q1: What is a PGT pneumatic fitting?
It is a straight reducer push-to-connect fitting used to connect tubes of different sizes.
Q2: What is a straight reducer fitting used for?
It is used for tube diameter conversion while maintaining straight airflow.
Q3: What materials are available for PGT fittings?
PGT fittings are available in nickel-plated brass and stainless steel options.
Q4: What tubing is compatible with PGT fittings?
PGT fittings are suitable for PU tubing and nylon tubing.
Q5: Can PGT fittings be customized?
Yes, OEM/ODM customization is available for size combinations, materials, and branding.
CTA
Looking for reliable PGT straight reducer push-to-connect pneumatic fittings?
Contact us today for OEM/ODM solutions, bulk pricing, and fast delivery.
