Specifications
| Parameter | Details |
|---|---|
| Product Type | Pneumatic Fittings |
| Model | KL-PE |
| Structure | Tee (T-Type) |
| Connection | Tube to Tube |
| Installation | Quick-Tight |
| Material | Nickel-Plated Brass |
| Operating Fluid | Air |
| Working Pressure | 0 – 1.0 MPa |
| Temperature Range | 0 – 60°C |
| Applicable Tubing | PU / Nylon Tube |
Nickel-plated brass tee pneumatic fittings provide reliable air distribution and long-term durability in pneumatic systems.
| Model: Model: (Example KL-PE4) |
| 4 |
| 6 |
| 8 |
| 10 |
| 12 |
| 14 |
| 16 |
Key Features
Quick-tight installation design
T-type tee structure for air splitting
Nickel-plated brass for corrosion resistance
Efficient multi-direction air distribution
Fast installation without tools
Stable and leak-resistant sealing
Applications
Pneumatic control systems
Used for splitting air supply into multiple directions
Industrial automation equipment
Supports multi-line air distribution in machinery
Air distribution systems
Enables efficient branching of airflow
Machinery equipment piping
Ideal for compact pneumatic layouts
Maintenance and modification scenarios
Allows easy expansion of air circuits
Product Function
KL-PE fittings are designed to split one compressed air line into two directions, enabling efficient air distribution within pneumatic systems.
Compared to straight fittings (KL-PU) or elbow fittings (KL-PL), KL-PE provides branching functionality, reducing the need for additional connectors and simplifying system design.
Product Structure & Size Range
KL-PE4 / KL-PE6 / KL-PE8 / KL-PE10 / KL-PE12
Tube sizes: 4mm → 16mm
T-type tee structure
Quick-tight locking mechanism
Compact multi-direction design
Why Choose Our Pneumatic Fittings
Professional KL series pneumatic fitting manufacturer
OEM / ODM customization for tee quick-tight fittings
Efficient air distribution solution for automation systems
Reliable nickel plated brass pneumatic connectors
Durable fittings for industrial environments
Fast delivery and global B2B supply support
FAQ
Q1: What is a KL-PE pneumatic fitting?
It is a tee quick-tight pneumatic fitting used to split air flow into multiple directions.
Q2: What is a tee pneumatic fitting used for?
It is used to branch one air line into two separate directions.
Q3: What is the difference between KL-PE and KL-PU?
KL-PE is a tee fitting for air distribution, while KL-PU is a straight union fitting.
Q4: What tubing is compatible with KL-PE fittings?
KL-PE fittings are suitable for PU tubing and nylon tubing.
Q5: Can KL-PE fittings be customized?
Yes, OEM and ODM customization is available for sizes and materials.
