Specifications
| Parameter | Description |
|---|---|
| Product Name | Low Temperature Resistant TPU Hose |
| Product Type | Special-purpose TPU pneumatic hose / low temperature resistant air tubing |
| Material | High-performance TPU |
| Working Medium | Compressed air and compatible pneumatic line applications |
| Key Properties | Hydrolysis resistant, UV resistant, wear resistant, weather resistant, and low-temperature flexible |
| UV Resistance | Grade 3.5 or higher |
| Chemical Resistance | Good resistance to oils and non-polar solvents |
| Low Temperature Performance | Remains flexible at low temperatures and maintains good coiling performance during low-temperature bending |
| Standard Colors | Yellow / Transparent |
| Tube Sizes | 8 × 5 mm, 10 × 6.5 mm, 12 × 8 mm |
| Roll Length | 100 m per roll |
| Carton Quantity | 8 × 5 mm: 1 × 6 rolls; 10 × 6.5 mm: 1 × 4 rolls; 12 × 8 mm: 1 × 3 rolls |
| Precautions | Use with caution above 60°C, in strong acid or alkali, highly polar solvents, chemical vapor environments, humid storage, or storage longer than 12 months |
| Typical Application | Pneumatic air lines, factory equipment, outdoor equipment, low-temperature environments, automation equipment, and maintenance projects |
| Selection Checks | Confirm tube size, air pressure, working temperature, color, fitting type, chemical exposure, storage condition, and installation environment before ordering |
Tube Size Options
| Tube Size, O.D. × I.D. | Color | Unit | Length | Carton Quantity |
| 8 × 5 mm | Yellow / Transparent | Roll | 100 m | 1 × 6 rolls |
| 10 × 6.5 mm | Yellow / Transparent | Roll | 100 m | 1 × 4 rolls |
| 12 × 8 mm | Yellow / Transparent | Roll | 100 m | 1 × 3 rolls |
Product Features
Low Temperature Flexibility
This low temperature resistant TPU hose is designed for pneumatic air line applications where standard PU tubing may become stiff in colder working conditions. It remains flexible at low temperatures and maintains good coiling performance during low-temperature bending.
Hydrolysis and Microbial Degradation Resistance
The hose is resistant to hydrolysis and microbial degradation, making it suitable for factory air lines, maintenance environments, and selected outdoor or humid working conditions when storage and installation requirements are properly controlled.
UV Resistance Grade 3.5 or Higher
With UV resistance of Grade 3.5 or higher, the hose provides better resistance to ultraviolet radiation and yellowing. This makes it suitable for applications where tubing may be exposed to light or outdoor equipment conditions.
Wear, Shear, and Tensile Resistance
The TPU material provides excellent resistance to wear, shearing, and tensile stress. It also offers high impact strength, high tensile strength, and good aging resistance for repeated pneumatic line use.
Resistance to Oils and Non-Polar Solvents
The hose offers good resistance to oils and non-polar solvents, making it suitable for selected industrial air line environments where standard tubing may be exposed to oil mist or non-polar solvent contact.
Better Durability Than Standard PU Tubing
Under the same operating conditions, this low temperature resistant TPU hose offers greater durability, longer service life, and a better appearance than standard PU tubing.
Applications
Low Temperature Pneumatic Air Lines
Used for compressed air routing in pneumatic systems where hose flexibility is required under colder working conditions.
Factory Automation Equipment
Suitable for automation machines, pneumatic control circuits, air tools, small cylinders, and factory air line connections.
Outdoor and Weather-Exposed Equipment
Applied in selected outdoor equipment or light-exposed installations where UV resistance, weather resistance, and aging resistance are important.
Maintenance and Replacement Projects
Used for replacing standard PU tubing in applications that require better low-temperature flexibility, wear resistance, and longer service life.
Oil-Mist Industrial Environments
Suitable for selected pneumatic systems where the hose may contact oil mist or compatible non-polar solvent conditions.
Precautions for Use
Use this hose carefully when the fluid temperature exceeds 60°C. High fluid temperature may soften the hose and reduce pressure resistance.
Avoid using the hose where the ambient temperature exceeds 60°C or where chemical vapors are present. High temperature may reduce hose pressure resistance, while chemical vapors may accelerate aging and cause cracking.
Do not use this hose for strong acids, strong alkalis, highly polar solvents, or highly corrosive media unless material compatibility has been fully confirmed.
Do not store the hose in humid conditions or for longer than 12 months. Long-term moisture exposure may cause hydrolysis, cracking, or premature hose failure.
Why Choose HOMIPNEU
HOMIPNEU supplies pneumatic hoses, TPU air hoses, PU tubes, PE tubes, PA nylon tubes, pneumatic fittings, air blow guns, air source treatment components, solenoid valves, cylinders, and related compressed air components for industrial automation and factory maintenance.
We help customers confirm hose selection details before ordering, including tube size, material, color, working pressure, temperature range, fitting type, chemical exposure, roll length, storage condition, and packaging requirement.
For distributors and industrial customers, HOMIPNEU provides stable sourcing support for low temperature resistant TPU hose, special-purpose pneumatic tubing, and related compressed air system components.
FAQ
What is the low temperature resistant TPU hose used for?
It is used for compressed air lines, pneumatic systems, automation equipment, factory air lines, outdoor equipment, and applications where better low-temperature flexibility is required.
How is it different from standard PU tubing?
Compared with standard PU tubing, this TPU hose provides better low-temperature flexibility, hydrolysis resistance, weather resistance, wear resistance, and longer service life under suitable operating conditions.
What sizes are available?
Available sizes include 8 × 5 mm, 10 × 6.5 mm, and 12 × 8 mm.
What colors are available?
The listed color options are yellow and transparent.
Can this hose be used outdoors?
It can be used in selected outdoor or light-exposed applications because it has UV resistance of Grade 3.5 or higher and weather-resistant properties. Working temperature and chemical exposure should still be checked before use.
Can this hose be used above 60°C?
Use with caution when fluid or ambient temperature exceeds 60°C. High temperature may soften the hose and reduce pressure resistance.
Can it be used for strong acids or strong alkalis?
It is not recommended for strong acids, strong alkalis, highly polar solvents, or highly corrosive media unless compatibility is fully confirmed before use.
How should this hose be stored?
Avoid humid storage conditions and do not store the hose for longer than 12 months. Long-term moisture exposure may cause hydrolysis, cracking, or premature hose failure.
What should be confirmed before ordering?
Please confirm tube size, color, working pressure, working temperature, fitting type, installation environment, chemical exposure, roll length, packaging requirement, and order quantity.
Custom Supply Support
HOMIPNEU supports OEM & ODM supply for low temperature resistant TPU hoses, special-purpose air hoses, PU tubes, PE tubes, PA nylon tubes, pneumatic fittings, air blow guns, air source treatment components, cylinders, and complete compressed air system components. Customers can provide tube size, color, roll length, packaging requirement, application environment, and expected quantity for accurate selection and supply.
