Details
| Attribute | Details |
| Product name | Directional Control Valve |
| Brand Name | HOMIPNEU |
| Model Number | SY3120-5LZD-M5 |
| Type | Gas Appliance Isolation Shut-Off Valves, Vacuum Relief Valves, Pressure Reducing Control Valves, Pressure Regulators, Air & Vacuum Release Valves, Air Valves & Vents |
| Product Type | 2/2 Way |
| Body material | Zinc alloy |
| Power | Pneumatic |
| Media | Gas |
| Medium | Filtered compressed air |
| Pressure | 0-10MPA |
| Working Temperature | -10°C ~ +50°C |
| Voltage | DC12V, DC24V or AC24V, AC36V, AC110V, AC220V, AC380V |
| Port Size | 1/8, 1/4, 3/8, 1/2 |
| Thread Size | G1/8, G1/4 |
| Effective Area | 2.5MM |
| Application | General Purpose |
| Place of Origin | Zhejiang, China |
| Customized support | OEM, ODM |
| Warranty | 1 years |
| After Warranty Service | Video technical support, Online support |
SPECIFICATIONS
| Model Series | SY3000 | SY5000 | SY7000 | SY9000 | |
| Using Fluids | Air | ||||
| Internally Piloted Type — Operating Pressure Range (MPa) | 2-Position, Single Solenoid | 0.15~0.7 | |||
| 2-Position, Double Solenoid | 0.1~0.7 | ||||
| 3-Position | 0.2~0.7 | ||||
| Ambient Temperature and Medium Temperature (°C) | -10 to 50 ℃ (non-freezing) | ||||
| Maximum Operating Frequency (Hz) | 2-Position (Single Solenoid / Double Solenoid) | 10 | 5 | 5 | 5 |
| 3-Position | 3 | 3 | 3 | 3 | |
| Manual Override Type | Non-locking push-button type; Screwdriver-actuated push-and-turn locking type; Manual push-and-turn locking type | ||||
| Pilot Valve Exhaust Method | Centralized exhaust for main and pilot valves | ||||
| Lubrication | Not required | ||||
| Mounting Method | Free | ||||
| Note) Shock / Vibration Resistance (m/s²) | 150 / 30 | ||||
| Protective Structure | Dust-proof (*IP65 for DIN-style socket and M8 connector types) | ||||
| According to IEC60529 | |||||
| Note) Shock Resistance: Tested using a drop-type shock tester, with one test conducted along the axial direction of the main spool and armature, and another perpendicular to it, under both energized and de-energized conditions; no malfunctions occurred (values represent initial performance). Vibration Resistance: Vibration tests were conducted along the axial direction of the main spool and armature, as well as perpendicular to it, across a frequency range of 45 to 2000 Hz under both energized and de-energized conditions; no malfunctions occurred (values represent initial performance). | |||||
2 Way 3 Port vs 5 Port Solenoid Valve
| Feature | 2 Way 3 Port Valve | 5 Port Valve |
|---|---|---|
| Port Number | 3 ports | 5 ports |
| Positions | 2 positions | 2 or 3 positions |
| Function | ON/OFF or exhaust control | Directional control |
| Cylinder Type | Single-acting cylinder | Double-acting cylinder |
| Airflow Control | Basic | Advanced switching |
| System Complexity | Simple systems | Complex automation systems |
Key Features
- 5/2 way directional control design
- Compact structure with high efficiency
- Fast switching response (≤15 ms typical)
- Low power consumption coil
- Suitable for manifold or standalone installation
Applications
- Pneumatic automation systems
- Industrial machinery
- CNC equipment
- Packaging machines
- Cylinder control systems
Widely used in automation systems for controlling airflow direction and driving double-acting cylinders with fast and reliable switching performance.
Why Choose Our Pneumatic Valve
- Professional SY3120-5LZD-M5 solenoid valve supplier with stable production capacity
- OEM / ODM customization available for SMC type directional control valve replacement projects
- Reliable 5/2 pneumatic valve for cylinder control systems and industrial automation
- High-quality pneumatic valve manufacturer in China with strict QC standards
- Compact M5 port air control solenoid valve for space-saving applications
- Fast delivery and global industrial supply support
FAQ
Q1: What is a SY3120-5LZD-M5 solenoid valve?
It is a 5/2 way directional control solenoid valve used to control airflow direction in pneumatic systems.
Q2: What does 5/2 way mean?
It means the valve has 5 ports and 2 positions, commonly used for double-acting cylinder control.
Q3: What is the port size of this valve?
It uses an M5 port connection for compact pneumatic systems.
Q4: What is the response time?
Typical response time is around 15 ms for fast switching.
Q5: Does it support OEM customization?
Yes, OEM/ODM services are available including voltage, wiring, and branding.
