3V Series Solenoid Valves for Single-Acting Cylinder Control
Date: 2026-07-03 Categories: Product Guide Views: 10Open Link in Markdown
Single-acting pneumatic cylinders need a valve that can both supply compressed air and release it when the actuator returns. This is one reason 3/2 way air solenoid valves are widely used in pneumatic automation. The 3V series provides several body and port size options for different machine layouts.
In a single-acting cylinder circuit, the valve sends air to extend or actuate the cylinder. When the electrical signal changes, the valve exhausts air so the spring or external force can return the actuator. This simple function is used in clamping, pushing, lifting, stopping, ejecting, and indexing operations.
Where 3V Series Valves Are Used
3V series valves are common in assembly stations, packaging equipment, fixture control, material handling systems, and pneumatic panels. Small machines may use the 3V110-06 3/2 Way Air Solenoid Valve G1/8, while general machine panels often use the 3V210-08 3/2 Way Air Solenoid Valve G1/4. Larger actuator circuits may require the 3V310-10 3/2 Way Air Solenoid Valve or 3V410-15 3/2 Way Air Solenoid Valve G1/2 depending on flow and port size.
| Application | Why a 3/2 Way Valve Fits |
|---|---|
| Single-acting cylinder extension and return | Supplies air and exhausts the actuator line |
| Pneumatic clamps and fixtures | Provides compact electrical control of air movement |
| Packaging stops and ejectors | Supports repeated short-stroke actuator cycles |
| Machine control panels | Organizes multiple air output signals in one panel |
| Auxiliary blow-off circuits | Switches compressed air on demand |
Model Selection by Machine Size
For compact fixtures and small air control points, the 3V110-06 3/2 Way Air Solenoid Valve G1/8 offers a smaller port direction and is easier to fit into tight spaces. For broader pneumatic machine use, the 3V210-08 3/2 Way Air Solenoid Valve G1/4 is often a practical choice because G1/4 is common in many pneumatic systems.
When a cylinder or air line needs more flow, the 3V310-10 3/2 Way Air Solenoid Valve provides a larger body direction. For bigger compressed air circuits and higher air demand, the 3V410-15 3/2 Way Air Solenoid Valve G1/2 supports G1/2 line layouts. Buyers should not select only by model number; they should confirm port size, coil voltage, flow requirement, and available mounting space.
Maintenance and Troubleshooting Notes
Slow switching, weak actuator movement, or unstable return action may come from low pressure, wrong voltage, blocked exhaust, dirty compressed air, or undersized flow capacity. Installing proper air source treatment before the valve group can help reduce contamination and moisture-related valve problems.
Buying Checklist for OEM and Maintenance Teams
- Confirm whether the cylinder is single-acting or double-acting.
- Choose the correct 3/2 way valve size for the air demand.
- Match coil voltage with the control system.
- Check DIN or lead wire connection requirements.
- Confirm exhaust clearance and panel mounting space.
Explore related valves in the Solenoid Valve product category.
