Specifications
| Parameter | Details |
|---|---|
| Product Type | Pneumatic Fittings |
| Model | KL-PB |
| Structure | Thread Tee (T-Type) |
| Connection | Tube to Thread |
| Installation | Quick-Tight |
| Material | Nickel-Plated Brass |
| Operating Fluid | Air |
| Working Pressure | 0 – 1.0 MPa |
| Temperature Range | 0 – 60°C |
| Applicable Tubing | PU / Nylon Tube |
Thread tee pneumatic fittings provide efficient air distribution and secure threaded connection in pneumatic systems.
Model: Model: (Example KL-PB4-M5)
| 4-M5 | 6-03 | 10-02 | 14-04 |
| 4-M6 | 6-04 | 10-03 | 16-02 |
| 4-01 | 8-01 | 10-04 | 16-04 |
| 4-02 | 8-02 | 12-01 | 16-06 |
| 6-M5 | 8-03 | 12-02 | |
| 6-01 | 8-04 | 12-03 | |
| 6-02 | 10-01 | 12-04 |
Key Features
Quick-tight installation design
T-type tee structure for air distribution
Threaded port for secure mounting
Nickel-plated brass for corrosion resistance
Compact multi-direction connection
Stable and leak-resistant sealing
Applications
Pneumatic control systems
Used for branching airflow with threaded connection
Industrial automation equipment
Supports multi-line air distribution
Air distribution systems
Ensures stable airflow splitting
Machinery equipment piping
Ideal for threaded interface connections
Maintenance and retrofit scenarios
Allows easy expansion of pneumatic circuits
Product Function
KL-PB fittings are designed to distribute airflow into multiple directions while providing a threaded connection point, enabling both branching and secure installation in pneumatic systems.
Compared to standard tee fittings (KL-PE), KL-PB adds threaded connection capability, making it suitable for equipment-mounted applications.
Compared to straight thread fittings (KL-PC / KL-PM), KL-PB provides air distribution functionality, improving system flexibility.
Product Structure & Size Range
KL-PB4 / KL-PB6 / KL-PB8 / KL-PB10 / KL-PB12
Thread types: M5 / G / R / NPT
Tube sizes: 4mm → 12mm
Thread tee structure
Quick-tight locking mechanism
Why Choose Our Pneumatic Fittings
Professional KL series pneumatic fitting manufacturer
OEM / ODM customization for thread tee fittings
Efficient air distribution solution for automation systems
Reliable nickel plated brass pneumatic connectors
Durable fittings for industrial environments
Fast delivery and global B2B supply support
FAQ
Q1: What is a KL-PB pneumatic fitting?
It is a thread tee quick-tight pneumatic fitting used for three-way air distribution and tube-to-thread connection.
Q2: What is a thread tee fitting used for?
It splits airflow while allowing connection to a threaded port.
Q3: What is the difference between KL-PB and KL-PE?
KL-PE is a tube-to-tube tee fitting, while KL-PB includes a threaded port.
Q4: What tubing is compatible with KL-PB fittings?
KL-PB fittings are suitable for PU tubing and nylon tubing.
Q5: Can KL-PB fittings be customized?
Yes, OEM and ODM customization is available for thread types and sizes.
