Mal Series 16mm Bore Size Small Pneumatic Air Cylinder For Sale

Specification Parameters Condition: New Warranty: 1 Year Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Retail, Construction works , Energy & Mining Weight (KG): 1.5 Video outgoing-inspection: Provided Machinery Test Report: Provided Marketing Type: Ordinary Product Warranty of core components: 1 Year Core Components: Engine, Motor, Pressure vessel, Gear, Pump Standard or Nonstandard: Standard Structure: Piston Cylinder Power: Pneumatic Body Material: Aluminum Place of Origin: Zhejiang, China Brand Name: HOMIPNEU Product name: MAL Series Mini Cylinder Model: MAL Application: Machinery Material: Alumium Alloy Working Pressure: 0.1-1.0MPa Bore size: 10-40 mm Stroke: NM Maximum Stroke: NM Port Size: M5-0.8(mm) Working Temperature: -20 to 80° Inner diameter mm   20 25 32 40 Action mode MSAL,MTAL series   Single action Other series   Double action Working medium   Air Operating pressure range Singel action   0.1-1.0MPa (14-145Psi) Double action   0.2-1.0MPa (28-145Psi) Guaranteed pressure resistance   1.5Mpa(215Psi) Working temperature   -20~70℃ Operating speed range   30-800 Stroke tolerance range   0~150+1.0 >150+1.4 Buffer form   Crash Pad Piping port   PT1/8 PT1/4
